The camera works when connected with a wire to Apple devices running the iOS operating system - iPhone, iPad. Connector type - Lightning or USB Type-C to choose from when ordering. The camera has a hard wire, which is more convenient to control the direction than with a soft one. The wire can be given the required shape in advance; it is flexible.
The application has the ability to take photos and record videos. The camera head is equipped with 8 LEDs, the wire has a smooth brightness control up to the complete shutdown of the backlight.
Waterproof according to the IP68 standard.
Included with the endoscope camera:
- hook attachment
- magnet attachment
- attachment with a miniature mirror for inspecting surfaces at 90° relative to the camera, for example, the cylinder walls of engines or pipes (before use, remove the disposable protective film from the glass).
The endoscope camera will be useful both for entertainment purposes at home and for work:
- in car repair shops to check the condition of pistons and cylinder walls through the holes of unscrewed spark plugs or injectors using a mini mirror and then assess the cost or feasibility of repairs; combustion chambers and valves through the holes of the removed intake/exhaust manifolds; assessing the condition of turbine blades without removing the unit through removed pipes; extracting torn off or accidentally dropped objects in hard-to-reach places using mini-hook or magnet attachments.
- in plumbing work, to eliminate blockages in bathrooms and toilets, inspect the condition of rain and sewer pipes.
- when carrying out electrical work, installing or repairing wiring in boxes and suspended ceilings, where access is extremely limited and subsequent dismantling for full access is advisable only after finding the problem location.
Specifications:
Lens diameter: 8.0mm
Resolution: 1280x960
Sensor size: 1/5 inch
Field of view: 70°
Frame rate: 30fps
Focal length: 5-10cm
Waterproof: IP67
Working temperature: 0°-70°C
Image format: MJPEG
Video format: MP4
Cable length: 2m
The camera does not have autofocus. The best resolution distance is 5-10cm. The resolution decreases as the distance increases or decreases.
